Miniature caged ball LM guide (SRS)

Structure and Features

Ball Retainer Type LM Rolling Guide SRS type has a structure with two rolling surfaces in a small body, and can withstand loads in all directions; for space-saving parts or parts with torque, only a single axis can be used. And. The use of a ball retainer eliminates friction between the balls. As a result, excellent high speed, low noise, good sound quality, long service life, and maintenance-free long-term operation are realized.

The use of a ball retainer eliminates friction between the balls and improves grease retention, thus reducing dust generation. In addition, highly corrosion-resistant stainless steel is used for the LM slider and LM track, and the SRS type has a low track section height and a compact structure with one steel ball row on each side. The SRS type can be installed in areas where space saving is required.

The SRS-type LM slider is lightweight and has low inertia because a portion of the slider (e.g., around the back hole of the ball) is made of resin and processed by insert molding technology.
